What is the formula for differential pressure flowmeter?

1. Basic formula expression: Q=K ⋅ C ⋅ ρΔ P Applicable scenarios: typical differential pressure flow measurement equipment such as standard orifice flow meters. Parameter description: K (instrument constant): determined by the structure of the flowmeter and needs to be determined through calibration experiments. For example, there is a significant difference in the K value between a Venturi tube and an orifice flowmeter. C (Orifice Plate Coefficient): Influenced by the ratio of orifice plate opening diameter β (β=d/D, where d is the orifice plate opening diameter and D is the inner diameter of the pipeline) and the pressure measurement method (corner joint/flange pressure measurement). The ISO 5167 standard provides a lookup table for this coefficient. Δ P (pressure difference): It can be directly measured by the differential pressure transmitter through leakage and closing, and it should be noted that the pressure measuring point should be located in the fully developed flow field area. Backcracking ρ (fluid density): Temperature and pressure compensation is required for gases, while temperature effects are mainly considered for liquids.

2. The difference between orifice flowmeter and balance flowmeter

Both orifice flowmeter and balance flowmeter belong to differential pressure flowmeter, and their core differences cover four dimensions: principle, structure, performance, and installation. Balance flowmeter has stronger comprehensive adaptability, but orifice flowmeter has lower cost and simpler structure.

. 1. Principle difference: Both are based on differential pressure measurement logic that generates pressure difference thr Differential pressure of orifice flowmeter

Differential pressure of orifice flowmeter

ough fluid throttling, relying on Bernoulli equation to calculate flow rate: the orifice flowmeter relies on a single thin plate with a central circular hole to achieve throttling, and a pressure difference is formed on both sides when the fluid flows through the orifice plate; The balanced flow meter adopts a porous symmetrical throttling structure, which allows the fluid to be distributed more evenly before and after throttling, and stably generates a measurable pressure difference. The structure difference of the orifice flowmeter is minimal, consisting only of a thin plate with a central circular hole, a pressure measuring device, and a measuring tube; The structure of a balanced flowmeter is more complicated, with multiple wheel leakage throttling holes distributed in the same plane. The shape, size, and distribution of the holes need to be customized and adjusted according to specific operating conditions. 3. The performance characteristics can be visually compared between the two through a table: | Performance dimension | Orifice flowmeter | Balanced flowmeter | ------- | ------- | | | Pressure loss | Large, which will increase subsequent operating energy costs | Small, can reduce long-term operating costs | Measurement accuracy | ± 0.5%~± 1% | ± 0.2%~± 0.5%, higher accuracy | Range ratio | 3:1~4:1, narrower range | Up to 10:1 or even higher, wider range | Anti pollution ability | High requirements for fluid cleanliness, easy to be affected Impurities affect measurement results | Strong anti fouling ability, suitable for fluid conditions containing impurities | 4 The installation requirements for orifice flow meters differ, with higher requirements for the upstream and downstream straight pipe sections. Generally,
