1. What are the types of mass flow meters?

2.1 minutes to learn about the requirements for the straight pipe section of the balance flow meter.

The requirements for the straight pipe section of the balance flow meter are as follows:

1. Length requirements for the upstream straight pipe section: The length should be ≥ 10D (D is the inner diameter of the pipeline), referring to the pipe section from the pipeline to the flow inlet end. Downstream straight pipe section: The length should be ≥ 5D, referring to the pipe section from the outlet end of the flowmeter to the rear.

2. Position and Tilt Angle Position: The upstream and downstream straight pipe sections should be kept horizontal or tilted towards the flow meter side, with a tilt angle of<1 °.

. Purpose: To ensure a full tube state, avoid gas accumulation or liquid precipitation, and maintain a stable fluid flow rate. III. Requirements for Interference Factors in Special Situations: If there are components in the pipeline that interfere with fluid flow, such as valves, elbows, tees, etc., the length of the straight pipe section needs to be extended to eliminate the disturbance. Installation environment: Avoid installing in areas with strong vibration or magnetic field interference to prevent affecting measurement accuracy. Stay away from flammable and explosive substances to ensure safety.

Fourth, other precautions. Cleanliness: There should be no impurities, rust, or dirt inside the pipeline to prevent wear or blockage of the flow meter.

. Maintenance space: The installation location should be easy to maintain and clean, with sufficient operating space reserved. Fluid direction: Ensure that the fluid flows in from the inle Requirements for straight pipe section of flowmeter

Requirements for straight pipe section of flowmeter

t end and out from the outlet end. After installation, actual testing is required to confirm that the direction is consistent with the design. Pressure and temperature: Maintain stable pressure inside the pipeline to avoid fluctuations affecting measurement. Select the appropriate flow meter based on the fluid temperature, monitor and protect the equipment during installation. Summary: The straight pipe section of a balanced flowmeter is required to cover multiple aspects such as length, position, environment, and maintenance. In practical applications, specific parameters need to be determined by combining technical manuals or consulting professional manufacturers (such as Hesheng Measurement and Control) to ensure measurement accuracy and equipment lifespan.

3. Requirements for straight pipe sections at the inlet and outlet of electromagnetic flowmeter

The requirements for straight pipe sections at the inlet and outlet of electromagnetic flowmeter are as follows: Inlet straight pipe section: Basic requirements: The inlet straight pipe section must meet a minimum length of 10 × DN (DN is the inner diameter of the measuring pipe). If the conditions permit, it is recommended to reach a length of 15 × DN, calculated from the electrode axis.

. Special working condition requirements: If there are mixing components such as valves, elbows, tees, and water pumps on the upstream side of the flowmeter, the length of the front straight pipe section should be greater than 20 × DN to eliminate the influence of mixing components on the fluid flow state and ensure measurement accuracy. Measurement requirements for mixed media: When measuring mixed media of different liquids, the distance between the mixing point and
