1. What is the working principle of a mass flowmeter? The core of a mass flowmeter is to directly or indirectly calculate the mass flow rate of a fluid by measuring the changes in physical parameters when the fluid flows through it, without the need for additional compensation for fluid density, temperature, and pressure parameters. ### 1. The principle of a thermal mass flowmeter relies on the difference in heat carried away by the fluid to calculate the mass flow rate. 1. Two temperature measuring elements are installed inside the sensor, one for active heating and the other as a reference for temperature measurement When the fluid is stationary, the temperature at two temperature measurement points is the same; When the fluid flows through, the heat of the heating element will be carried away by the fluid. The larger the fluid flow rate, the more heat will be carried away, and the temperature difference between the heating element and the reference element will be greater By calibrating the temperature difference and power parameters, the mass flow rate can be directly converted without being affected by fluid density or pressure. ### 2. The principle of Coriolis mass flowmeter is currently the most accurate type of mass flowmeter, which works by utilizing the Coriolis effect.

1. The measuring tube generates high-frequency vibration through an electromagnetic drive device.

2 When fluid flows through a vibrating measuring tube, it will be subjected to the Coriolis force, causing additional twisting deformation of the measuring tube The sensors installed at both ends of the measuring tube will detect the phase difference of this deformation, which is proportional to the mass flow rate of the fluid, and can also directly measure the density of the fluid. ### 3. The principle of differential pressure mass flowmeter is to achieve mass flow calculation through the combination of differential pressure and disassembly density measurement using a travel high hood. 1. Use orifice plates, nozzles and other throttling devices to generate differential pressure signals, which are proportional to the square root of the volumetric flow rate By using a density sensor to measure fluid density in real-time, the final mass flow rate is calculated using the formula mass flow rate=square root of differential pressure x fluid density x calibration coefficient. ### 4. The principle of impeller mass flowmeter combined with impeller speed and fluid density to achieve flow calculation

1. The fluid drives the impeller to rotate, and the speed is proportional to the volumetric flow rate. 2 Paired with temperature and pressure sensors to correct fluid density, and then multiplied by density to obtain mass flow rate, the accuracy is slightly lower than the first two types of professional mass flow meters.

2. Measurement principle and signal characteristics of mass flowmeter

Characteristics, selection and application of mass flowmeter 1 Introduction Flow rate, like temperature, liquid level, pressure and other parameters, is an important parameter that needs to be monitored at any time in the chemical production process.
