Krohne Mass Flow Meter Manual PDF: Zero Point Balancing Under Pressure and Sizing Protocols
Quick Answer: Zero point balancing on a Krohne Coriolis mass flow meter must be performed at operating pressure and not at atmospheric pressure. A correct sizing protocol prevents most zero point shift. Send Silver Instruments your pressure in bar, temperature in °C, pipe size in DN, and flow range in kg/h for a direct replacement quote.
We get many questions from engineers and buyers who download the Krohne mass flow meter manual PDF and then ask about zero point balancing under pressure and sizing protocols. This article gives the exact points that matter. We supply Coriolis mass flow meters from Silver Instruments for oil and gas, chemical, water and wastewater, food and beverage, and marine applications.
Why Zero Point Balancing Under Pressure Counts
The Krohne mass flow meter manual PDF makes one point clear. Zero point balancing must happen under process pressure. Many engineers skip this step. They calibrate the zero point with the line open to atmosphere. Then the meter sees 8 bar or 20 bar during production. The zero point shifts. The result is a small offset that becomes a large error at low flow rates.
Most engineers skip this part because it takes time. The process fluid must be inside the sensor. The line must be blocked. The pressure and temperature must be stable for 10 to 15 minutes. Only then do you start the zero point calibration. In practice this means the meter must be installed with block valves and a way to verify process pressure at the sensor.
What the Krohne Manual PDF Tells You About Pressure
Coriolis mass flow meters measure mass flow directly. The zero point is the output when there is no flow. Under pressure the sensor tubes deform slightly. The deformation shifts the zero point. The shift is small but important. A meter rated for 0.1 percent accuracy can lose low flow accuracy if the zero point is set at 1 bar and then the line runs at 16 bar.
We have seen this on customer sites many times. A paint manufacturer in Vietnam checked the zero point at 2 bar but ran the line at 7 bar. The meter drifted by 0.42 kg/h at low flow. That is enough to ruin a batch ratio. After retesting at 7 bar the meter held the zero point within specification.
Sizing Protocols for Coriolis Meters
Sizing a Coriolis mass flow meter is not only about pipe size. The sizing protocol must include flow range, pressure, temperature, fluid density, viscosity, and required pressure drop. A DN15 meter may handle 5 to 3000 kg/h. A DN50 meter may handle 1000 to 35000 kg/h. These ranges change with viscosity and pressure. For high viscosity fluids above 100 cP the pressure drop grows quickly. You need a larger meter or a different tube design.
Here is the thing. A correct sizing protocol prevents most zero point issues. If the meter is too large, the flow velocity is low. The signal to noise ratio drops. The zero point becomes more visible in the measurement. If the meter is too small, pressure drop rises and the sensor may operate outside its stable flow range. Both cases cause problems in the field.
We size Silver Instruments Coriolis meters from DN15 to DN200. Pressure ratings go up to 160 bar. Temperature ratings go up to 200 °C. Temperature compensation on the transmitter uses a PT100 input. Outputs include 4-20 mA HART, pulse, and Modbus RTU. Wetted parts are 316L stainless steel as standard. For aggressive chemicals we offer Hastelloy C22. For food and beverage we offer EHEDG approved options.
Real Sizing Example for a Diesel Line
For a 2 inch line moving diesel at 40 bar and 70 °C with flow
Why Customers Switch from Krohne to Silver Instruments
Some customers use the Krohne manual PDF as a training document. Then they buy a compatible Coriolis meter from Silver Instruments. The reason is price and delivery time. We supply the same measurement principles with 316L stainless steel wetted parts and 4-20 mA HART output. We also provide a pressure test certificate and zero point calibration record with each meter. The model number and tag plate information match your pipe size and flow range.
We do not sell a copy of the Krohne meter. We sell a Coriolis mass flow meter that follows the same sizing protocols and zero point balancing rules. For water and wastewater plants in Latin America we often ship within 2 to 3 weeks. For chemical plants in the Gulf region we provide Ex proof versions for ATEX Zone 1 or IECEx. Tell us the hazardous area classification. We will match the right transmitter and housing.
Zero Point Balancing Procedure at Site
Use this procedure after installation. Close the downstream block valve. Fill the sensor with the process liquid. Open the upstream valve. Wait 15 minutes for temperature to stabilize. Check the pressure gauge at the sensor. It must match normal operating pressure. Then start the zero point adjustment from the transmitter menu or with the handheld communicator. After the adjustment, verify the zero point reading is within 0.02 percent of full scale. Record the value in the shift log.
For gas applications the procedure is different. The sensor must be filled with gas at operating pressure. The zero point is more sensitive to temperature changes. Wait 20 minutes before starting. We recommend a zero point check every six months for custody transfer. For batching and blending lines a yearly check is enough unless the fluid changes.
FAQ
Do I need to zero the Coriolis meter at operating pressure? Yes. The Krohne manual PDF and field data show that pressure changes the tube stiffness slightly. A zero point set at atmospheric pressure will shift when line pressure rises above 10 bar.
What flow range should I tell Silver Instruments for sizing? Give us the minimum and maximum flow rate in kg/h or t/h. Also give the normal flow rate. This helps us select a meter that stays within the stable flow range.
Can Silver Instruments supply a Coriolis meter for hazardous areas? Yes. We supply ATEX Zone 1, Zone 2, and IECEx versions. Tell us the gas group and temperature class. We will match the transmitter and housing.
What process connections are available for Coriolis meters? We offer ANSI, DIN, JIS, and tri clamp connections. Common sizes are DN15, DN25, DN40, DN50, DN80, DN100, DN150, and DN200. Flange ratings go from 16 bar to 160 bar.
How fast can I get a quote? Send us your pressure in bar, temperature in °C, pipe size in DN, flow range in kg/h, and fluid name. We reply within 24 hours on business days. Call Tel: +86-25-68650347 or WhatsApp: +86-25-52155837. WeChat: +86 15365082610.
Silver Automation Instruments supplies industrial flow meters and process instruments to Southeast Asia, Oceania, Latin America, Africa, and the Middle East. Ask for a Coriolis mass flow meter quote with zero point balancing and sizing protocol included.
