Euromag Flow Meter Catalog: High-Performance Electromagnetic Sensors for Water Utility
Quick Answer: The Euromag flow meter catalog for water utility work lists electromagnetic sensors from DN15 to DN2000 with EPDM, hard rubber, PTFE, and PFA liners. Standard accuracy is 0.5 percent of reading with an option for 0.2 percent of reading. Silver Automation Instruments supplies these meters with 4-20 mA HART, pulse, RS485 Modbus, and IP68 remote sensor options.
What the Euromag Catalog Covers for Water Utility
The catalog includes electromagnetic sensors for raw water, potable water, wastewater, sludge, and desalination brine. Tube sizes cover DN15 to DN2000. Pressure ratings range from PN10 to PN40. The compact version installs in tight metering pits. The remote version keeps the transmitter above flood level. In practice, water utilities in Manila, Jakarta, and Lima often choose remote mount because underground chambers collect water during the rainy season.
Sensor and Liner Selection
Electromagnetic flow meters need a non-conductive liner. For drinking water with chlorine, EPDM is common. For raw water with sand, hard rubber handles abrasion better. For seawater desalination feed lines, PTFE or PFA lining protects the sensor body from corrosion. Electrode choices are 316L for most water applications, Hastelloy C for raw sewage, and titanium for seawater. The catalog states minimum conductivity at 5 µS/cm. That covers almost all municipal water except ultra-pure water.
Most engineers skip this part, but liner choice affects long term maintenance. A wastewater plant in Vietnam replaced 12 meters last year because the original liner swelled in high chlorine backwash water. Silver Instruments supplied EPDM lined Euromag sensors with 316L electrodes. The replacement program cost less than rebuilding the old meters.
Accuracy and Flow Range
Standard Euromag water utility sensors hold 0.5 percent of reading from 0.3 m/s to 10 m/s. The optional high accuracy version reaches 0.2 percent of reading across the same range. For custody transfer and revenue metering, use the 0.2 percent version. For network monitoring, the standard version is enough. Flow range depends on pipe size. A DN100 meter covers 8 to 280 m³/h. A DN300 meter covers 70 to 2500 m³/h. A DN600 meter covers 280 to 10000 m³/h. Send us your pipe size in DN, flow range, and maximum pressure. We will select the correct sensor diameter.
Outputs and Integration
Water utility control systems vary. The Euromag catalog supports 4-20 mA HART, passive pulse, active pulse, and RS485 Modbus RTU. Some utilities still use battery powered telemetry. For those sites, the flow meter output can drive a data logger directly. Power supply options are 85 to 265 V AC and 24 V DC. The converter housing is IP67. The remote sensor can be ordered with IP68 rating for submerged installation. If you need a seawater flow meter for a desalination plant, specify titanium electrodes and a PTFE liner with IP68 remote cable.
Here is the thing. Integration
_600x400.jpg)
Typical Water Utility Applications
Euromag electromagnetic sensors from this catalog appear in raw water abstraction lines, water treatment plant inlet and outlet headers, clear well discharge, booster station discharge, district metered areas, and wastewater effluent lines. Desalination plants use them for seawater intake, brine reject, and permeate transfer. Food and beverage plants use the same meter for wash water and CIP return water. In one case, a paint manufacturer in Southeast Asia used a DN80 Euromag meter to batch raw water for washing mixing tanks. The meter paid for itself in under 8 months through reduced waste.
Why Water Utilities Choose Euromag from Silver Instruments
Silver Automation Instruments supplies the Euromag catalog as a cost effective electromagnetic flow meter range for water utility networks. We provide technical selection, wiring support, and spare parts from one contact point. Shipments cover Southeast Asia, Oceania, Latin America, Africa, and the Middle East. Most DN15 to DN300 meters ship within 7 to 12 working days. Bigger sizes from DN350 to DN2000 ship within 18 to 25 working days. We also handle sea freight and courier delivery to your nearest port or project site.
For a quote, send us your pressure in bar, temperature in °C, pipe size in DN, flow range, and water type. Contact Silver Automation Instruments at Tel: +86-25-68650347, Whatsapp: +86-25-52155837, or WeChat: +86 15365082610.
FAQ: Euromag Electromagnetic Sensors for Water Utility
What conductivity does a water utility electromagnetic flow meter need?
The Euromag catalog requires at least 5 µS/cm. Most raw water, potable water, and wastewater exceed this. If your water is demineralized or ultra pure, select a different meter type.
Can these sensors handle raw water with sand or solids?
Yes. Hard rubber liners protect against sand erosion. Electrode materials like 316L or Hastelloy C resist wear in most municipal raw water and sludge lines.
What liner and electrode combination works for chlorinated drinking water?
Use EPDM liner with 316L electrodes. EPDM tolerates chlorine residuals and standard water temperatures from 0 to 70 °C.
Can I install a mag meter in an underground vault?
Yes. Use the remote mount version with IP68 sensor and IP67 converter. Mount the converter above the flood line. Remote cable lengths can be ordered up to 100 meters.
How do I send an inquiry for a Euromag water utility flow meter?
Send us your pipe size in DN, flow range, maximum pressure in bar, water type, and temperature in °C. Contact Silver Automation Instruments at Tel: +86-25-68650347, Whatsapp: +86-25-52155837, or WeChat: +86 15365082610.
