1. What does a positive displacement flow meter mean?

A positive displacement flow meter is a volumetric flow meter; Hello! My answer to the question you raised has been provided. Please take a look! If you have any questions, please feel free to reply to me! I hope my answer is helpful to you! If you are satisfied, please click the Adopt as Satisfied Answer button in a timely manner. If a friend of the clients comments point Satisfied in the upper right corner, please approve! It is my motivation to answer questions and also brings you knowledge and wealth value O (∩ _ ∩) O. Thank you!!!

2. Positive displacement flowmeter?

Positive displacement flowmeter, also known as PD flowmeter or PDF, is the most accurate type of flow meter. It uses mechanical measuring elements to continuously divide the fluid into individual known volume parts, and measures the total flow volume based on the number of times the measuring chamber sequentially and repeatedly fills and discharges that volume part of the fluid. His representatives include gears, scrapers, and rotary pistons. The internal design of a positive displacement flowmeter includes a space that constitutes a certain volume. The internal rotation of the flowmeter rotates under the pressure of the fluid flowing in from the inlet. With the rotation of the rotor, the fluid flows from the inlet to the outlet. At this time, during the rotation process, a certain volume space is formed between the rotor and the flowmeter housing, filling this space with fluid. With the rotation of the rotor, the fluid is continuously sent to the outlet. If the volume of the space is designed and the number of rotations of the rotor is measured, the volume given by the spac

positive displacement flow meter|thermal flow meter

e can be obtained, thereby obtaining the volume of fluid flowing through it. In addition, based on the number of rotations of the rotor measured per unit time, the instantaneous flow rate can be obtained, which is the measurement principle of the volumetric flowmeter. PDF has high measurement accuracy, with a basic error of generally ± 0.5% R, and special ones can reach ± 0.2% R or higher. Usually used in expensive media or situations that require accurate measurement. PDF does not affect the accuracy of measurement when there is distortion in the velocity field of rotating flow and pipeline obstruction components, and there is no requirement for a pre straight pipe section. This is of great significance in on-site use. PDF can be used for measuring high viscosity fluids. The range is wide, generally ranging from 10:1 to 5:1, with some reaching 30:1 or even larger. PDF is a direct reading instrument that does not require external energy and can directly obtain the cumulative total amount. It is clear and easy to operate. In indirect mass flow measurement using a combination of volumetric flow meters, compared with velocity derived volumetric flow meters, PDF directly measures the volume, and the factors affecting the volume are simpler. In high-pressure natural gas measurements that are not suitable for density measurement, the compressibility coefficient of gases that are difficult to handle can be indirectly obtained using PDF.

3. The meaning of positive displacement flow meter

The meaning of positive displacement flow meter is volumetric flow meter.

. It is an instrument that determines flow rate by measuring the number of times a fluid flows through a chamber of a known volume. Here are some key poi
